What does Quanmeter mean? ——Note: A certain type of turbine flowmeter
Quanmeter belongs to the trade name and is a gas turbine flowmeter used for trade measurement. Abbreviated as Q-type turbine flowmeter. The body length is short, the volume is small, the performance is excellent, and the price is low, making it an economical turbine flowmeter with high cost-effectiveness. In addition to measuring common types such as natural gas, crude oil gas, ethane based gas, and gas, it can also measure special forms of oxygen, acetylene gas, high sulfur petroleum gas, and other corrosive gases. There are two types of connection methods: flange and clamp. No need for straight pipe sections. Working principle: The gas entering the instrument is accelerated by the contracting reverse fluid, and then acts on the turbine blades through the inlet channel. The turbine shaft is installed on a ball bearing, and the number of turbine revolutions proportional to the volume of the measured gas is transmitted to a multi digit gauge after multi-stage gear reduction, displaying the volume of the measured gas. Performance characteristics: Low cost, short body turbine flowmeter Accuracy: 0.2Qmax ≤ Q ≤ Qmax... ± 1% Qmin ≤ Q ≤ 0.2Qmax... ± 2% Range ratio: 1:20 High pressure (1:50) Flow range: 6-1600 m; /h (210 - 56,500 ft³ /h) Caliber: DN 50-150 Pressure rating: PN 10-100, ANSI 150-600 Short time overload
1.6 * Qmax Instrument without damage Title length
1.5 * DN ductile iron body (GGG-40) or cast iron self-lubricating or forced lubrication method suitable for vertical or horizontal installation with low-pressure pulse generator, optional high-end pulse generator. Connection method: DIN flange connection (same as Chinese
2. What does concompressor mean?
Compressor English [k ə m ˈ pres ə (r)] American [k ə m ˈ pr ɛ s ɚ] n. Compressor, plural: compressors Example: The design feature of QC185 gas turbine low pressure compressor was introduced. The characteristics of the QC185 gas turbine low pressure compressor design scheme were introduced. The Performance prediction of centrifugal compressor takes a very important rolein its research and application. The performance prediction of centrifugal compressors plays a very important role in their research and application.
3. Kneeling down to seek professional English vocabulary for thermal energy and power engineering
English professional vocabulary for thermal power plantsAcid cleaning, acid washing, interstage, leakage between stages, coal bunker, raw coal hopper, interchange/distillation/bump disturbance, excess air, excess air, inverter, conversion switch, induced draft fan, induced draft fan, isolate each other, steam drum items, components, sub distribution transformer, low-voltage plant transformer, journal bearing support, 6kV station board, 6KV public distribution panel, kilovolt, 6kV unit board, 6KV distribution panel, low pressure cylinder/casting (LP) Low pressure cylinder A: Ampere large scale integrated circuit actuator actuator LED light emitting diode adapter, connector, light/ignite ignition air circuit breaker air circuit breaker Linear Variable Differential Transformer (LVDT) - Linear Differential Transformer - Air Dry Analysis - Linearizatio
